MITCalc Multi pulley calculation 1.21

Sponsored links:
license: Shareware ($16.00)
downloads: 554
size: 1.6328125 MB
updated: 2017-07-11

Buy Now

Add to Basket
x64 compatible software

64-bit download
MITCalc
The calculation is developed for geometrical designs of belt and chain transmissions with more sprocket wheels (max. 15). Application is developed in MS Excel, is multi-language, supports Imperial and Metric units and solves the following main tasks: - Calculation of the necessary length of the belt (chain) using known positions and diameters of sprocket wheels - Achieving the desired (table) length of the belt / chain using a change in the position of the selected sprocket wheel. - Calculation of geometry (angles of wrapping, numbers of teeth in engagement, axis distances, etc.) - Calculation of the radial force acting on the sprocket wheel axis. - Support of 2D CAD systems (AutoCAD, AutoCAD LT, IntelliCAD, Ashlar Graphite, TurboCAD, BricsCAD, ZWCAD). This module is a part of MITCalc - Mechanical and Technical Calculation Package for gear, belt and chain drives, springs, beam, shaft, bolt connection, shaft connection, tolerances and many others

User Rating: 2.8 (4 votes)

x64 compatible software
OS: Win2000, Windows XP, Windows 7 x32, Windows 7 x64, Windows 8, Windows 10, WinServer, WinOther, Windows 2000, Windows 2003, Windows Server 2012, Windows Tablet PC Edition 2005, Windows Media Center Edition 2005, Windows Vista, Windows Vista x64
Requirements: Microsoft Excel (2000, XP, 2007, 2010, 2013, 2016...)


MITCalc Multi pulley calculation screenshot
